FL38 (LC-15A2L)
OPERATION MANUAL
MAIN POWER
TV/VIDEO
CH ( )/(
)
Volume (+)/(–)
MENU
Power/Standby indicator
A green indicator lights when the power is on and a red
indicator lights when in the standby mode (the indicator
will not light when the main power is off).
Rear control panel
Remote sensor window
(The actual location is not visible.)
To change the vertical angle of the LCD TV
set, tilt the screen up to 10 degrees forward or
20 degrees backward. The TV set can also be
rotated 90 degrees horizontally. Please adjust
the angle so that the TV set can be watched
most comfortably.
Front view
Note:
• TV/VIDEO, CH(, )/( ), and Volume (+)/(–) on
the main unit have the same functions as the
same buttons on the remote control. Funda-
mentally, this operation manual provides a
description based on operation using the
remote control.
POWER INPUT
DC 12 V
Headphones
Antenna
AUDIO OUT (R)
AUDIO OUT (L)
S-VIDEO
VIDEO
AUDIO (R)
AV-IN1 (21-pin Euro-SCART)
AUDIO (L
)
AV-IN 2
Rear view
Controls
T
erminals
