Loewe FL38 - BLOCK DIAGRAMS; MAIN BLOCK DIAGRAM

ITEMNMB DESCRIPTION
LIST-PART-NMB LAST-DATE
POSNR.
KURZTEXT
BESTELLNR.
ENTF-DAT.60415A70
Q4310 TRANS BF1100WR SOT343 + TRANSISTOR 344-27268
Q4410 TRANS BF1100WR SOT343 + TRANSISTOR 344-27268
Q4836 TRANS BC847B SOT23 TRANSISTOR 344-14974
Q4853 TRANS BC847BW SOT323 TRANSISTOR 344-27272
W1001 FOLIENSTECKVERB. 20-POL RM0,5 CONTACT LEDGE 326-28933
W1002 STIFTW.VERT 7-P NAT 2R50 EH LV326-11 CONTACT LEDGE 326-20908
W1002 KONTAKTLEISTE 21POL RM2,54 LV326-27320 CONTACT LEDGE 326-27320021
W1007 BUCHSENLEISTE 5POL RM5,08 LV326-28942 CONTACT LEDGE 326-28942005
W1008 FLACHSTECKER,GEBOGEN" UG 2 " LV PLUG 321-82232001
W1009 FOLIENSTECKVERB. 50-POL RM0,5 CONTACT LEDGE 326-28934
W1012 FLACHSTECKER,GEBOGEN" UG 2 " LV PLUG 321-82232001
W1013 STIFTW.VERT 11-P NAT 2R00 PH JST CONTACT LEDGE 326-28935
W1014 BUCHSENLEISTE 6POL RM5,08 LV326-28942 CONTACT LEDGE 326-28942006
W1015 FLACHSTECKER,GEBOGEN" UG 2 " LV PLUG 321-82232001
W1018 FLACHSTECKER,GEBOGEN" UG 2 " LV PLUG 321-82232001
W4100 KOAX-BUCHSE SOCKET 323-27599
W4200 KONTAKTLEISTE 6POL RM5,08 LV326-27320 CONTACT LEDGE 326-27320016
W4800 KONTAKTLEISTE 4POL RM5,08 LV326-27320 CONTACT LEDGE 326-27320014
W4800 KONTAKTLEISTE 5POL RM5,08 LV326-27320 CONTACT LEDGE 326-27320015 26.01.2001
X4651 QUARZ 4,000000 MHZ HC49U3 LOW PROFILE CRYSTAL OSCILLATOR 385-27752
X4701 FILT. OFW K 6263 K FILTER 290-25214
X4751 FILT. OFW K 9463-M FILTER 290-25323Y20
X4771 FILT. OFW K 9461-M FILTER 290-25216Y20
X4831 PIEZO FILTER 5,5MHZ/5,742MHZ LV020 CERAMIC FILTER 386-27630020
X4832 PIEZO FILTER 4,5 MHZ LV020 CERAMIC FILTER 386-27305020
Dienstag, 19. März 2002
Seite 8
