Loewe FL38 - REMOVING OF MAJOR PARTS; Main PWB Disassembly; Terminal PWB Disassembly

ITEMNMB DESCRIPTION LIST-PART-NMB LAST-DATE
POSNR.
KURZTEXT
BESTELLNR.
ENTF-DAT.60415A60
Q1029 TRANS BCX69-25 TRANSISTOR 344-24714
Q1030 TRANS BF 840 SMD TRANSISTOR 344-28018
Q1031 TRANS BF550 SOT23 TRANSISTOR 344-23563
Q1032
TRANS BC847BW SOT323
TRANSISTOR
344-27272
Q1033 TRANS BC857BW SOT323 LV030 TRANSISTOR 344-28404
Q1101 TRANS 2SA1729-1 TRANSISTOR 344-90354943
Q1102 TRANS 2SC4520-1 TRANSISTOR 344-90354944
Q1201 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q2003 TRANS 2SC2712Y-1 TRANSISTOR 344-90354933
Q2004
TRANS DTC144EE-1
TRANSISTOR
344-90354937
Q2005 TRANS DTA144EE-1 TRANSISTOR 344-90354945
Q2006 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q201 TRANS 2SC2712Y-1 TRANSISTOR 344-90354933
Q202 TRANS 2SC2712Y-1 TRANSISTOR 344-90354933
Q203 TRANS FMY3/////-1 TRANSISTOR 344-90354934
Q204
TRANS 2SC2712Y-1
TRANSISTOR
344-90354933
Q302 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q303 TRANS DTC314TK-1 TRANSISTOR 344-90354936
Q304 TRANS DTC314TK-1 TRANSISTOR 344-90354936
Q305 TRANS DTC314TK-1 TRANSISTOR 344-90354936
Q308 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q4106
TRANS DTC144EE-1
TRANSISTOR
344-90354937
Q4107 TRANSISTOR UMG4/////-1 TRANSISTOR 344-90354970
Q4702 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4709 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4752 TRANS DIGITAL SOT323 NPN 50V 100MA 47K TRANSISTOR 344-28555 31.12.1999
Q4754 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4772
TRANS DIGITAL SOT323 NPN 50V 70MA 47K+
TRANSISTOR
344-27270
Q4772 TRANS DIGITAL SOT323 NPN 50V 100MA 47K TRANSISTOR 344-28555
Q4774 TRANS DIGITAL SOT323 NPN 50V 70MA 47K+ TRANSISTOR 344-27270
Q4804 TRANS BC857W SOT323 TRANSISTOR 344-27468
Q4804 TRANS BC857BW SOT323 LV030 TRANSISTOR 344-28404
Q4832 TRANS BCR198W SOT323 PNP TRANSISTOR 344-27269
Q4833
TRANS BC847BW SOT323
TRANSISTOR
344-27272
Q701 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q702 TRANS 2SK2503-1 TRANSISTOR 344-90354938
Q703 TRANS 2SC2712Y-1 TRANSISTOR 344-90354933
Q707 TRANS DTC144EE-1 TRANSISTOR 344-90354937
Q708 TRANS FMMT718-1 TRANSISTOR 344-90354939
Q709
TRANS DTC144EE-1
TRANSISTOR
344-90354937
Q710 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q751 TRANS FZT1053A-1 TRANSISTOR 344-90354940
Q752 TRANS FZT1053A-1 TRANSISTOR 344-90354940
Q753 TRANS 2SA1162Y-1 TRANSISTOR 344-90354935
Q754 TRANS DTC114YE-1 TRANSISTOR 344-90354941
Q757
TRANS UPA606T-1
TRANSISTOR
344-90354942
10
FILT. OFW K 9463 M
FILTER
290-25323
SPEZIALTEILE SPECIAL PARTS
20 DECKEL LID 501-87236011
21 DECKEL LID 501-87236011
21 KABLBAUM DISPLAY CONNECTING CABLE 171-90355905
2-12 SCHAUMGUMMI FRAME 549-90354989
22 15" LCD-PANEL PICTURE TUBE 345-90354999
2-2
RUECKWANDAUFKLEBER
FRAME
549-90354979
25 TYPENSCHILD INDICATING UNIT 663-90354991
Donnerstag, 17. Mai 2001
Seite 5
