DYNAMIC MOTION SYSTEM - SYSTEM MANUAL // PAGE 21
5.3.2 ADJUSTING THE TABLE TO A MEMORY POSITION
Version A (without double-click function):
2
Press and hold the required Memory Position Key (e.g. 2).
The Table Top will move until the saved Table Top height has been reached. If you re-
lease the Key before the Memory Position is reached, the table will stop.
2
Release the Memory Position Key
7
The display shows the Table Top height (e.g. 73 cm)
Version B (Auto-Movement with double-click function):
INFO The double-click function is available only for DYNAMIC MOTION systems sold in US
markets. It is not activated as standard.
INFO
If you press any Key while the table moves to a Memory Position, the Table Top will stop
moving immediately. To continue, you must select the Memory Position again.
CAUTION
Risk of minor or moderate injury through unauthorized modications
The rmware is delivered with a deactivated double-click function. If you activate this
function, the gradings of the safety functions according to EN ISO 13849-1 PL b, Category
B, are no longer valid, as the legal requirements in the standard are no longer met.
• If you activate the function, perform a new risk new assessment to meet the higher
safety requirements (EN 60335-1). These cannot be met by the DYNAMIC MOTION
system
• LOGICDATA is not liable for injuries or damage caused by activating the dou-
ble-click function
2
Double-click the required Memory Position Key (e.g. 2)
The table will move to the Memory Position. You do not have to hold the Key
The display shows the Table Top height (e.g. 73 cm)
