11
Make sure to x the transit bolts prior to moving the washing machine.
How to connect from the left side
~80cm
~90cm
110 -135cm
min. 60cm
max. 100cm
~40cm
~130cm
How to connect from the right side
Levelling the Washing Machine
There are levelling feet on the underside. They must be adjusted to make sure the washing
machine is level.
1. On each foot, loosen the lock ring by
turning it clockwise.
2. Adjust all feet by rotating each upwards
or downwards.
3. Use a spirit level to ensure the washing
machine is level.
4. Tighten each lock ring by turning them
anti-clockwise (towards the washing
machine body).
Ensure all lock rings are tightened securely. Check that the feet are still bolted to the washing
machine - if they’re unbolted, the washing machine will move around.
Hose and Cable Lengths
Water Supply Hose
Points to remember
• Follow the instructions in this section to avoid water leaks.
• Don’t connect the hose to a combination tap.
• Don’t twist, squash, modify or cut the hose.
• Disconnect the mains cable.
• Attach the transit bolts.
