Part IV Faults Diagnosis

- 32 -

4-9 Fault of electric starting system

(Repair or replace)

(Charge or replace)

(Replace)

Dose the

electric relay

(switch) have

click sound?

No click sound

Battery fault

Short circuit or broken circuit of lead wire or

connecting plug

Fuse burn-out

(Repair or replace)

Fault of engine switch

(Repair or replace)

(Charge or replace)

(Repair or replace)

Have click

sound

Undervoltage of battery

Short circuit or broken circuit of lead wire or

connecting plug

Fault of starting engine

(Repair or replace)

(Replace battery)

Storage battery

cannot be

charged

Fault of charging coil

Fault of battery

(Repair or replace)

Short circuit or broken circuit of lead wire or connecting plug

(Repair or replace)

Fault of magneto rotor
