Part I Technical Specifications
- 3 -
1-2 Technical parameters
The rated power of the engine indicated in the Manual is the net output power (net power) at 3,600 rpm of an
engine under the production status measured in accordance with SAE J1349. For mass production engines, the
value may vary.
The actual power of engine installed on the terminal may vary in output, which depends on several factors
including the rotating speed of engine during practical use, environmental conditions, maintenance and other
variants.
Single-engine Power Unit Power
Type of Engine
Double-cylinder, four-stroke-cycle, forced-
valve
Air displacement
(diameter of cylinder × stroke)
764ml（80mmX76mm）
Maximum power
(kW/3600rpm)
19
Maximum torque (N·m)
Corresponding rotating speed (rpm)
52/2800
Fuel consumption rate
(g/kW·h)
≤ 350
Idle speed
(rpm)
1,800±150
Speed fluctuation rate ≤ 10%
Compression ratio
8.7:1
Starting mode Electronic start
Direction of rotation Anticlockwise (output terminal)
Valve clearance (mm)
Inlet valve 0.10 ~ 0.15
Exhaust valve 0.15 ~ 0.20
Spark plug
RC12YC
Spark plug gap (mm) 0.7 ~ 0.8
Ignition mode Transistorized magneto ignition
Type of air filter Double filter cartridge
External dimensions (mm)
L × W × H
507×502×690 507×502×500
Net weight (kg)
50 49
