LONCIN LC2V80FD Maintenance Manual

Chapter V Disassembly & Repair
5-2-6 Flywheel and ignition coil
a. Disassembly/assembly
Disassembly:
D
isassemble
disassembly of flywheel
Do not tap
disassemble it with a commercially
available flywheel puller
Assembly:
Clean the conical part of the crankshaft
and
flywheel without engine oil or dirt
before installation
Flywheel
Air guide sleeve
Inner hexagon
screw
M6×20
Starting engine part
Chapter V Disassembly & Repair
- 44 -
Flywheel puller
Disassembly:
isassemble
the ignition coil prior to the
disassembly of flywheel
;
Do not tap
the flywheel with hammer and
disassemble it with a commercially
available flywheel puller
.
Assembly:
Clean the conical part of the crankshaft
flywheel without engine oil or dirt
before installation
.
Ignition coil
Assembly:
Align
two cams at the inner side
with the small holes on the
flywheel.
Avoid excessive force in
disassembly and assembly so as to
avoid breaking the blade
Blade wheel
Assembly:
Prior to
check if the insulation is
cracked or damaged so as
to avoid electric leakage
Charging coil
Flywheel
Torque: (22 ~ 28) N•m
Flange bolt M8 × 95
Air guide sleeve
Inner hexagon
Starting engine part
Ignition coil
Assembly:
two cams at the inner side
with the small holes on the
flywheel.
Avoid excessive force in
disassembly and assembly so as to
avoid breaking the blade
.
Blade wheel
Assembly:
Prior to
installation,
check if the insulation is
cracked or damaged so as
to avoid electric leakage.
Torque: (8 ~ 12) N•m
Flange bolt M6 × 30
Torque: (80 ~ 100) N•m
Prevent the rotation of
flywheel with tool
during the disassembly
and assembly.
Flywheel bolt M12 × 35
