LONGER LK2 - Wiring; Screen Wiring

13
9. Wiring
1. X motor line 2. X limit switch line 3. E-axis motor line
4. E-axis break detection 5. Z-axis motor line 6.Z-axis limit switch
10. Screen wiring
