INSTALLING THE STIFFENERS
To nalise wheel installation, you will nd 2 types of stiffeners in the case delivered with the bike, compatible
with either standard or thru axle setups.
These stiffeners must be installed after tightening the chain, wheel and adjustment rollers.
The stiffeners are held in place by 2 FHC M4x10mm
screws which you will nd in the case with the
ttings. Tighten to a torque of 1Nm using a torque
wrench tted with an Allen HEX2 head.
1 Right stiffener for thru axle
2 Left stiffener for thru axle
3 Right stiffener for standard axle
4 Left stiffener for standard axle
