7
EN
1 I Set aside all the parts you will need for your selected build.
2 I Clean and degrease the parts and the fork ends with a suitable degreaser, excluding the M3x5mm
screws already coated with threadlocker.
3 I Prepare a torque wrench with both HEX 6 and TORX T10 heads.
EXPLODED VIEW OF THE FRONT WHEEL FITTINGS FOR A STANDARD AXLE
BEFORE ASSEMBLING
1 Smooth washer, diameter 10 x2
2 Threaded washer, diameter 10 x2
3 M3x5 screw - Torx T10 - 1Nm - threadlocker ex.: LOCTITE 243 x4
