Look T20 - Installing Thru Axle Front Wheel Fittings

8
EN
1 I Place the threaded washer on the inside of the
left fork end and press it rmly into place.
2 I Place the smooth washer on the outside of the
left fork end and press it rmly into place. Pre-tighten
using 2 M3x5 screws.
3 I Repeat step 1 on the right side (the threaded
washer is a symetrical piece and can be mounted
on either side).
4 I Insert the M12 nut on the outside of the right fork
end and press it rmly into place. Pre-tighten using
2 M3x5 screws.
INSTALLING THE THRU AXLE FITTINGS
Inside
Outside
Outside
