page 14
Picture pc-board DK-DCDRV / DK-S3DRV
X3
X2
X1
S1
LED6
LED4
LED1
LED2
LED5
T
T T
T
T
TT
T
D
D00.0050.6-02
L
L
L L
L
L
LED6
UZmin
LED4
UZmax
LED1
ovr cur
LED2
drv low
LED5
drv hi
T = MOSFET (power transistor)
D = diode
!!! CAUTION !!!
at all positions where cables are attached, the longer screws are used (A+ A- +UZ -UZ).
The rest of the ISOTOP screws are the short ones.
