Lorex LHV1000 SERIES User Manual

Connecting a PTZ Camera
(LHV1000 Series)
20
You can connect PTZ cameras (not included) to the system. You must use Lorex 720p
wired PTZ cameras with the system. Lorex 720p wired PTZ cameras can accept PTZ
commands directly through the video cable. There is no need to run special wiring to use
PTZ cameras.
To connect a PTZ camera to the system:
1. Connect the camera video cable to one of the Video IN ports on the system.
2. Right-click and click Main Menu. Enter the system user name (default: admin) and
password (default: 000000) if prompted.
3. Click
>Setting>Pan/Tilt/Zoom.
4. Under Channel, select the channel your PTZ camera is connected to.
5. Under Control Mode, select HDCVI.
6. Under Protocol, select DH-SDI.
7. Click OK. You can now control your PTZ camera using the system.
20.1 Controlling a PTZ Camera (Local DVR)
1. In Live View, double-click the channel that has the PTZ camera connected to open in
full-screen.
2. Right-click and click Pan/Tilt/Zoom. Enter the system user name and password if
prompted. The PTZ menu opens.
3. Use the on-screen PTZ controls to control the camera.
#LX400014; r. 2.0/15899/15899; en-US
156
