Lotus Service Notes Section MR
Component Location
Other electrical components may be found as follows:
- CDLmodule;passengersideofscuttlebeamverticalface.
- Alarmcomponents;seesub-sectionMR.1.
- Horns;onebeneaththefrontendofeachfrontlongeron,alignedwithaperturesintheairintakeduct.
Accessible after removal of front undertray.
- Ambientairtemperaturesensor;mountedinRHsideoftheairintakeduct,clippedtotheundertraypylon.
Accessible after removal of front undertray.
- Audiospeakercross-overunits;oneoneachendofthescuttleverticalrearface.
- Forwardcrashsensor;oneontheoutboardfaceofeachfrontsubframelongeron,towardsthefront.Ac-
cessible after removal of the front undertray.
- Enginemanagementcomponents;seesectionEMR.
- TPMSmodule;inboot,onbackofLHwheelarch.
- Reversingcameramodule;inboot,onLHSofreartransom.
MR.7 - AUDIO EQUIPMENT
Operating instructions for the unit fitted are contained in a separate booklet supplied by the equipment
manufacturer. The audio set will operate with the ignition key inserted, and in any of its positions, including
the‘0’lockposition.
On cars fitted with a 2-DIN audio system and 175mm display screen, the following features are also in-
cluded:
- AM/FMradio;
- CDaudio;
- DVDvideo,operableonlywiththeparkingbrakeengaged;
- i-podtoi-podvideointeraction/control;
- MP3player;
- Satellitenavigation;
- IntegratedmicrophoneforBluetoothphoneoperation;
- When set is switched on, automatic display from reversing camera when reverse gear is engaged.
- Note that the screen should be cleaned occasionally with a lint free, spectacle polishing cloth.
Note
• The‘satnav’system includes a road network safety camera database,whichmaybeactivatedatthe
owner’srequestwhenthesystemissetup.Ifusingthevehicleinterritorieswheresuchafeatureisillegal,
itistheowner’sresponsibilitytoensurethatthesystemisde-activated.
• Notethatthequalityofradioreceptionwillvaryaccordingtoaudioequipmentfittedandlocalareasignal
strength.
Speakers: Amainspeakerisfittedintoeachofthedoortrimpanels,andahighfrequency‘tweeter’incorporated
into each end of the dash fascia panel. In addition, some cars are fitted with a single sub-woofer, low freqency
speaker in the right hand rear quarter trim panel.
Door speakers - Alpine LUK-SB01B (4-speaker base spec.):
145mm aperture, 63mm depth
Door speakers - Alpine LUK-SB02T: (4/5-speaker high spec.):
145mm aperture, 63mm depth
Sub-woofer - Alpine SWE 843 (5-speaker high spec.):
183mm aperture, 111mm depth
Tweeters - Alpine LUK-ST01:
42mm aperture, 12mm depth
Security: Someaudiosetsfeaturearemovablefrontpanel;Fordetails,refertothesetmanufacturer’slitera
ture.
