Lotus Evora User Manual

Lotus Service Notes Section EMR
Page 17
Intake Air Temperature
P0111 Intake Air Temperature Sensor 1 Circuit Range/Performance
P0112 Intake Air Temperature Sensor 1 Circuit Low
P0113 Intake Air Temperature Sensor 1 Circuit High
Description
The combined sensor which measures both Mass Air Flow (MAF) and Intake Air Temperature (IAT) is incorpo-
rated into the air box. The IAT sensor is a thermistor device which changes resistance with temperature. As
air intake temperature decreases the thermistor resistance value increases, and conversely as air temperature
increases so the thermistor resistance value decreases.
Sensor connections
Sensor Connector Description ECU Pin ECU Connector
1 IAT Signal J3 48 Way (Centre)
2 IAT Ground E3 48 Way (Centre)
3 Battery Voltage - -
4 MAF Ground J4 48 Way (Centre)
5 MAF Signal G1 48 Way (Centre)
Sensor characteristics
IAT-20°C(-4°F) 13.6–18.4kΩ
IAT20°C(68°F) 2.21–2.69kΩ
IAT60°C(140°F) 0.50–0.67kΩ
P0111
2009/02
