Page 18
Lotus Service Notes
Section EMR
P01
12
Monitor:
•
Continuous
Disable Criteria:
•
None
Enable Criteria:
•
Enginerunning
Malfunction Criteria:
•
Inletairtemperature>1
19°C(246°F)fortime>1.5secs
Potential failure modes:
•
Signalshortcircuit
•
Sensorfailure
Diagnostic Mask:
•
TheMILwillbeilluminatedifthesefaultsarepresentfor2consecutivetrips.
P01
13
Monitor:
•
Continuous
Disable Criteria:
•
None
Enable Criteria:
•
Enginerunning
Malfunction Criteria:
•
Inletairtemperature<–40°C(–104°F)fortime>1.5secs
Potential failure modes:
•
Signalopencircuit
•
Sensorfailure
Diagnostic Mask:
•
TheMILwillbeilluminatedifthesefaultsarepresentfor2consecutivetrips.
2009/02
89
91
