I340 GB 06 16

M06 - SLAVE 01 OUTPUTS (n=1…16) UoM Default Range

P06.n.01 Output OUTn function n=1…8 See

Step x Output function table

=9…16

OFF

P06.n.02 Channel number x n=1…8 OFF/1 – 99

x=1…8

n=9…16

x=1

P06.n.03 Output normal/reversed NOR NOR - REV

Note: This menu is divided into 16 sections, which refer to 16 possible digital outputs OUT01…OUT16 that can be managed by DCRG8/DCRG8IND slave 1,

of which OUT01..OUT08 on the basic device and OUT09…OUT16 on any expansion modules.

P06.n.01 – Choice of the function for the selected output (see programmable output functions table).

P06.n.02 – Channel number associated with the function programmed in the previous parameter. Example: If the output function is set to Alarm Axx and this

output is to be energised for alarm A31, then set the value 31.

P06.n.03 – Sets the state of the output when P06.n.01 is inactive (OFF): NOR = Output de-energised; REV = Output energised.

M07 – SLAVE 02 OUTPUTS (n=1…16) UoM Default Range

P07.n.01 Output OUTn function n=1…8 See

Step x Output function table

n=9…16

OFF

P07.n.02 Channel number x n=1…8 OFF/1 – 99

x=1…8

n=9…16

x=1

P07.n.03 Output normal/reversed NOR NOR - REV

As previous menu but referred to slave 02.

M13 – SLAVE 08 OUTPUTS (n=1…16) UoM Default Range

P13.n.01 Output OUTn function n=1…8 See

Step x Output function table

n=9…16

OFF

P13.n.02 Channel number x n=1…8 OFF/1 – 99

x=1…8

n=9…16

x=1

P13.n.03 Output normal/reversed NOR NOR - REV

As previous menu but referred to slave 08.

...

P05.01 – Defines whether the system is used in master-slave configuration or not. With OFF, the system works with a single controller (normal configuration).

If COM1 or COM2 is set, working in master-slave mode, the setting indicates which channel is used to communicate between controllers.

P05.02 – Defines whether the current device is a master or a slave and in this case, which is its number.

P05.03… P05.10 – Enables the operation of individual slaves.

M05 – MASTER / SLAVE UoM Default Range

P05.01 Master-Slave function OFF OFF

COM1

COM2

P05.02 Device role Master Master

Slave01

Slave02

Slave03

…
