Lovibond MD100 User Manual

55
MD100_6 07/2016
GB
General notes
Correct filling of the vial:
Replacement of batteries:
Correct position of the vial (Ø 24 mm):
CAUTION:
To ensure that the instrument is water proof:
• seal ring (E) must be in position
• battery compartment cover (B) must be fixed with the four screws
If the batteries are removed for more than one minute the date and time menu starts auto-
matically when the photometer is switched on the next time.
AAA/LR 03
AAA/LR 03
AAA/LR03
AAA/LR03
(D) batteries
(E) seal ring
(C) notch
(F) instrument back
(B) battery compart-
ment cover
(A) screws

Lovibond MD100 Specifications

General

Display	LCD
Type	Portable Photometer
Wavelength Accuracy	± 1 nm
Operating Temperature	0 – 40 °C
Auto - OFF	Yes
Measurement Range	Varies depending on parameter
Accuracy	Varies depending on parameter
Light Source	LED
Sample Volume	10 ml
Parameters	Multiple (depends on the model)
Optics	High-quality interference filters
