AIS | HOOK series
AIS | HOOK series
AIS
The marine Automatic Identication System (AIS) is
a location and vessel information reporting system.
It allows vessels equipped with AIS to automatically
receive position, speed, course and vessel identity
information from other AIS-equipped vessels.
If an AIS device is connected, all targets detected
by the device can be displayed.
AIS setup
Before using AIS, your unit must be set to the
same Baud rate as your AIS device.
To select a Baud rate:
1. Access the settings menu.
2. Select NMEA 0183 and press ENTER.
3. Access the Baud rate dropdown menu
on the NMEA 0183 settings dialog.
4. Select the same Baud rate used by
your AIS device.
5. Select Save and press ENTER.
NOTE: Your unit must be set to Advanced
mode to access NMEA 0183 settings
(Requires optional Power/NMEA cable
000-0127-49)
