Lowrance HOOK-4x - Cursor; Advanced Mode; Restore Defaults

10
11
Basic operation | HOOK X series
Basic operation | HOOK X series
Standby mode
Lowers power consumption by turning o sonar
and the display.
Press the PWR/LIGHT key to
access the Backlight dialog.
Select Standby and press ENTER.
Press any key to resume normal
operation.
Restore defaults
Resets unit options and settings
to defaults.
NOTE: Leaving your unit in Standby
mode when your boat is not is use will run
down your battery.
Cursor
The keypad moves the cursor around the display,
allowing you to scroll the map, select map items
and review sonar history.
Press MENU and select Return to vessel or Exit
cursor mode to clear the cursor.
Advanced mode
Enables advanced features and settings.
The following features are enabled when Ad-
vanced mode is turned on:
• Units (Enables distance, speed, depth,
temperature, and bearings options)
• HOOK-5x & HOOK-7x only:
NMEA 0183 Output (Requires optional
Power/NMEA cable 000-0127-49)
