Lowrance HOOK-4x User Manual

8
9
Basic operation | HOOK X series
Basic operation | HOOK X series
Combo pages
Press the PAGES key twice to switch active
panels. The page menu for active page will be
displayed when the MENU key is pressed. The
active panel is denoted by an orange border.
Accessing the Settings menu
Accessing menu items
The keypad and ENTER key are used to select
menu items and open submenus. Use the keypad
to highlight the desired item and press ENTER.
x2
Sonar page
Sonar menu
Two-panel page
Horizontal panel

Lowrance HOOK-4x Specifications

General

Display Size	4.3 inches
Resolution	480 x 272 pixels
Frequency	83/200 kHz
GPS	No
Waterproof Rating	IPX7
Backlight	LED
Operating Voltage	12V DC
Transducer Included	Yes
Power Output	200W RMS
Display Type	Color TFT
Operating Temperature	-15°C to +55°C
Mounting Type	Bracket mount
