Specications | HOOK X series
Specications | HOOK X series
HOOK -4x & HOOK-5x
General
Case Size
HOOK 4x: 6.6” H (168 mm) x 3.6” W
(96 mm); 7.5” H (189 mm) with bracket
HOOK-5x: 5.4” H (136 mm) x 6.9”
W (174 mm); 5.9” H (151 mm) with
bracket
Display
HOOK-4x: (4.3” diagonal) 16-bit color
TFT LCD
HOOK-5x: (5” diagonal) 16-bit color
Full color VGA Solar MAX™ Plus TFT
Waterproof
standard
IPX7
Backlight LED (11 levels)
Communications
HOOK-5x: NMEA 0183 Output
(Requires optional Power/NMEA cable
000-0127-49)
Power
Transmit Power 500 W RMS
Power
Requirement
12 V
Voltage Input 10 to 17 V
Current drain
Typical: 1.1 A
Fuse type 3-amp Automotive
Sonar
Max depth
300 ft (91 m) 455/800 kHz
1000 ft (305 m) 83/200 kHz
2500 ft (762 m) 50/200 kHz
Available trans-
ducer frequencies
455/800 kHz
50/83/200 kHz
High/Medium/Low CHIRP
Max speed
70 mph
Transducer
HDI 50/200 kHz (Low/High CHIRP)
HDI 83/200 kHz (Medium/High CHIRP)
83/200 kHz (Medium/High CHIRP)
Transducer cable 20 ft (6 m)

Lowrance HOOK-4x Specifications

General

Display Size	4.3 inches
Resolution	480 x 272 pixels
Frequency	83/200 kHz
GPS	No
Waterproof Rating	IPX7
Backlight	LED
Operating Voltage	12V DC
Transducer Included	Yes
Power Output	200W RMS
Display Type	Color TFT
Operating Temperature	-15°C to +55°C
Mounting Type	Bracket mount
