Specications | HOOK X series
Specications | HOOK X series
HOOK -7x
General
Case Size
5.3” H (234 mm) x 9.2” W (136 mm);
5.9” H (151 mm) with bracket
Display
(7” diagonal) 16-bit color Full VGA
Solar MAX™ color TFT
Waterproof
standard
IPX7
Backlight LED (11 levels)
Communications
NMEA 0183 Output (Requires optional
Power/NMEA cable 000-0127-49)
Power
Transmit Power 500 W RMS
Power
Requirement
12 V
Voltage Input 10 to 17 V
Current drain
Typical: 1.1 A
Fuse type 3-amp Automotive
Sonar
Max depth
300 ft (91 m) 455/800 kHz
1000 ft (305 m) 83/200 kHz
2500 ft (762 m) 50 kHz
Available trans-
ducer frequencies
455/800 kHz
50/83/200 kHz
High/Medium/Low CHIRP
Max speed
70 mph
Transducer
HDI 50/200 kHz (Low/High CHIRP)
HDI 83/200 kHz (Medium/High CHIRP)
83/200 kHz (Medium/High CHIRP)
Transducer cable 20 ft (6 m)

Lowrance HOOK-4x Specifications

General

Display Size	4.3 inches
Resolution	480 x 272 pixels
Frequency	83/200 kHz
GPS	No
Waterproof Rating	IPX7
Backlight	LED
Operating Voltage	12V DC
Transducer Included	Yes
Power Output	200W RMS
Display Type	Color TFT
Operating Temperature	-15°C to +55°C
Mounting Type	Bracket mount
