Lowrance HOOK-4x User Manual

12
13
Pages | HOOK X series
Pages | HOOK X series
Sonar page
Displays the water column moving from right to
left on your unit’s screen.
Fish arches
Surface Clutter
Range scale
Bottom
Pages
DownScan page
The Downscan page shows the water column
moving from right to left. You can overlay
downscan sonar on the conventional sonar page
by selecting DownScan Overlay on the Sonar
settings menu.
Structure
Fish
Surface clutter
Range scale

Lowrance HOOK-4x Specifications

General

Display Size	4.3 inches
Resolution	480 x 272 pixels
Frequency	83/200 kHz
GPS	No
Waterproof Rating	IPX7
Backlight	LED
Operating Voltage	12V DC
Transducer Included	Yes
Power Output	200W RMS
Display Type	Color TFT
Operating Temperature	-15°C to +55°C
Mounting Type	Bracket mount
