PART ILLUSTRATIONS
GENERAL INFORMATION
Illustrations
Directional Reference
Part Order
Istructions
▶ GROUP NAME
: Detail classiflcation name for parts.
▶ SECTION NAME
:Classiflcation name for parts.
▶ COMPONENTS
: The components of an assembly are identifled by a bracket.
▶ NO.
: Reference numbers are assiqned to parts in the figure.
INTERCHANGEABILITY
: Indicates the interchangeabillty of parts due to design change
Orders must give the complete description, correct part number, the total amount required, the
product model, all the necessary serial numbers, the method of shipment and the shipping
address.
The individual parts in their normal relationship to each other. Reference numbers are used in the
illustrations. These numbers correspond to those in the "Number" column and are followed by
the quantity required and description.
"Right hand" and "left hand" sides are determined by standing at the rear of the unit and facing
in the direction of forward travel.
Indicates that a new part can be used instead of an old part when you
order this part, plese order new part.
★ Due to our policy of continuously improving products, The information contained herein is
subject to change withour notice
indicates that either parts can be used.
~4265-99999
5265-00001~
indicates that a part has a serial number break.
When you order this part, please order a part according to the serial
number of the Loader.
indicates that either parts can not be used.
- 25 -
