MOUNTING FRAME ASSEMBLY
NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40373769 FT605-11100-01 MOUNTING FRAME-LH 1
2 40373770 FT605-11200-01 MOUNTING FRAME-RH 1
3 40369945 FT605-11300-02 GRILL GUARD 1
4 40228616 10191-M1205-40 HEX.BOLT-HT, M12-1.75P 40L 20
5 40228642 10316-M1200 WASHER-SPRING, M12 20
- 26 -
