DUAL BUCKET ASSEMBLY
NO LS PART.NO PART.NO DESCRIPTION QTY I.C SERIAL OR DATE
1 40386958 FTB01-50800 BUCKET W.A., 50" PIN TYPE(LIGHT DUTY) 1
2 40386969 14123-25189-N PIN ASS'Y, Ø25-189L 4
40435691 14124-25189-N PIN ASS'Y, Ø25-189L 4
2020.08.01~
3 40388881 14512-24037-01 SPACER, Ø45-37L 8
4 40228656 14021-10000 PIN-RING, Ø10 4
40228633 1021M-M2404 NUT-SELFLOCK, M24-1.5P 4
2020.08.01~
- 34 -
