LS tractor MT122 - Range Gear Shift Lever; 4 WD Lever

3 -11
▶ When driving on the road, disengage the 4WD. If not, it may cause damage of
drive line and serious accident. After working, before coming out from the field,
select 2WD.
▶ When driving the tractor at high speed while the 4WD is engaged, sharp steering
may cause a accident.
(2) 4WD lever
z Stop the tractor completely before operating the
4WD lever.
z Push the lever forward to engage the four wheel
drive(4WD).
z Pull the lever backward to disengage 4WD.
z Four wheel drive (4WD) is effective for the
followings.
- When traction is needed in plow ground.
- When working on slippery ground.
- When working with tiller on hard ground.
- When crossing a ridge
(1) Range gear shift lever
z Low speed, neutral and high speed is available.
▶ Before operating range gear
shift lever, HAVE TO STOP the
tractor completely.
Caution
Range gear shift lever
Caution
High
Low
4WD lever
2WD
4WD
