5 -8
(4) Turn signal lights, Lights and Horn
z Check the operation of lights, turn signal lights and horn
▶ Use the bulb of rated capacity.
▶ In case of using the improper bulb, it may cause a failure of electric system.
Notice
Illuminating Lights Light bulb specification
Headlights
(Low beam / High beam)
12V 35W-H8 / N/A
Turn signal lights (front / rear) 12V 21W
Side lights (front / rear) LED
Stop lights / Taillights (rear) LED / LED
Work light(s) (optional) 12V 27W (Roll-bar)
Instrument panel lights and indicators LED
Turn signal
light switch
Light switch
z If the light is OFF suddenly when operating the switch, check the problems as followings.
1. Check the relating fuse in the fuse box.
2. Check the light bulb. If necessary, replace it by a new one as referring to below.
To Next Page
