4 -27
(10) Recommended Maximum Specification of Implements
No. Implements Specification MT122, MT125
1 Trailer Maximum vertical load See section 4-4-(3) in this manual
2 Mid mower Max working width 1524 mm (60 in)
3 Rear mounted mower Max working width 1524 mm (60 in)
4 Rear mounted sprayer Maximum weight 150 kg (331 lb)
5 Pulling type sprayer Maximum weight 800 kg (1600 lb)
6 Rotary Tiller Max tilling width 1280 mm (50 in)
7 Bottom plow Maximum width 1100 mm (43 in)
8 Manure Spreader Maximum volume 800 kg (1600 lb)
9 Front grader Max working width 1400 mm (55 in)
10 Rear blade Max working width 1370 mm (54 in)
11 Front loader
Max lift capacity
(Bucket pivot point)
402 kg (886 lb)
12 Box blade Max working width 1280 mm (50 in)
13 Backhoe Max digging depth 1978 mm (78 in)
14 Snow Blade Max working width 1370 mm (54 in)
15 Snow Blower Max working width 1370 mm (54 in)
z When attaching implements to the tractor, refer to the followings recommended as maximum
specification of each implement. DO NOT attach bigger implements than this specification. For other
implements, contact your authorized local dealer.
