3 -48
Down speed control knob
Fast
Slow & Lock
④ Down speed control knob (Roll-bar
type)
It is use to adjust the down speed of the 3-point
linkage. Turn the down-speed control knob to
the right direction for slower down speed, and to
the left direction for faster down speed.
If turning the knob right direction fully, the
implement will be fixed and even if lowering
down the position control lever, the implement
does not let down.
- Tiller: Slow in down speed
- Plough: Fast in down speed
When working in hard ground, slow down the
down speed to avoid the bounding of the
implements.
▶When driving on the road, replacing tiller blades or removing grass around the tiller
blades, turn the down-speed control knob clockwise slightly to lock.
▶The knob rotates about two revolutions. Do not over-tighten the knob. It may cause
damage to the control valve and connection parts.
Warning
