LS tractor XR4140 - Instruction for Safe Operation; The Name of each Part

To Next Page

To Previous Page

2 -1

2. Instruction for Safe Operation

Instrument panel

Steering wheel

Driver’s

Seat

Sub step

Head lights

Bonnet (Hood)

Front ballast weight

(optional)

Front axle

Fender

(1) The name of each part

① Roll-Bar type

Fuel tank

ROPS

(Roll bar)
