5 -39
▶ The filters are made of specially treated media with a rubber sealing strip bonded
around the sides. Take care not to damage the element during installation.
Notice
Cabin
air filters
Knobs
Filter
cover
(5) Replacing Cabin air filters
Before servicing the filters, switch off the blower
and close all the cabin doors and windows.
Cabin air filters are installed on the left and right-
hand side under the cabin roof.
Unscrew the knobs under the roof and remove
the covers and filter elements as shown in the
right figure.
Clean both filter chambers with a damp, lint-free
cloth.
Replace the cabin air filters with a new one.
Re-install the filter covers and tighten the knobs.
