6 -8

6-6. System diagram

Heater evaporator

Fan motor

Evaporator core

Heater core

Hot water

Control panel

Engine

Compressor

Fan

Radiator

Condenser

w/receiver drier

Quick coupler

Expansion valve

Heater lose

Cooler hose

Electric line
