Lucent Technologies MERLIN LEGEND Release 6.1 Network Reference

MERLIN LEGEND Communications System Release 6.1 Network Reference
555-661-150
Issue 1
August 1998
Call-Handling Scenarios
Page 2-49Network Configuration Scenarios
2
Table 2–9. Scenario 2: Facilities Planning, Calls Originating within the private network and Going to the PSTN
Component System C: Chicago, IL (Area Code: 312) System D: Palo Alto, CA (Area Code: 650)
DS1 Switch Type MERLIN LEGEND-PBX MERLIN LEGEND-Ntwk
ARS Access Code 99
Switch
Identifiers
Programmed on
This System
01 for a system more than 200 miles away
(System D)
02 for a system more than 200 miles away
(System C)
Remote Access
Code and COR
for UDP and
ARS Calls via
This System
Remote Access Code: 889
All tie (T1-emulated voice and data)
Outward Unrestricted
Barrier Code Required (ignored for UDP extension
and non-local ARS calls)
Disallowed List 7
FRL=3
Remote Access Code:326
All tie (T1- emulated voice and data)
Outward Unrestricted
Barrier Code Required (ignored for UDP extension
and non-local ARS calls)
Disallowed List 7
FRL=3
Centralized
VMS/AA
Integrated VMI calling group extension: 7771
Local dial plan members: Extensions for system
ports used to connect VMS/AA
Message waiting light updates for non-local
subscribers compete for tandem tie trunks and
touch-tone receivers with other voice and data
traffic.
Integrated VMI calling group extension: 7771
VMI conversion number (non-local dial plan
member): 6999
UDP routing over route 1, T1-emulated voice tie,
FRL=0, voice, all dialed digits are absorbed and the
digits 7771 are prepended.
