MERLIN LEGEND Communications System Release 6.1
Network Reference
555-661-150
Issue 1
August 1998
Call-Handling Scenarios
Page 2-79Network Configuration Scenarios
2
Table 2–19. UDP Extension Ranges: Scenario 4
System E Local Dial Plan:
5400–5499; 5610–5669
Centralized VMS/AA: 7771
Trunks 5801-5880
System F Local Dial Plan:
2200–2259; 2400–2449
Integrated VMI calling Group
for Routing to Centralized
VMS/AA: 7771
Trunks 2801-2880
System G Local Dial Plan:
4530–4599; 4600–4601
Integrated VMI calling Group
for Routing to Centralized
VMS/AA: 7771
Trunks 4801-4880
System H Local Dial Plan:
1230–1299; 1450–1499
Integrated VMI calling Group
for Routing to Centralized
VMS/AA: 7771
Trunks 1801-1880
Extension Range: 2200–2259
Pattern: 01
Route 01
Pool=4230, tandem PRI trunks
FRL=0, Both
Extension Range: 5400–5499
Pattern: 01
Route 01
Pool=5260, tandem PRI trunks
FRL=0, Both
Extension Range: 5400–5499
Pattern: 01
Route 01
Pool=8240, tandem tie trunks
FRL=2, Voice
Extension Range: 5400–5499
Pattern: 01
Route 01
Pool=6700, tandem PRI trunks
FRL=0, Voice
Extension Range: 2400–2449
Pattern: 10
Route 01
Pool=4250, tandem PRI trunks
FRL=1, Data
Extension Range: 5610–5611
Pattern: 07
Route 01
Pool=5281, tandem PRI trunks
FRL=5, Data
Extension Range: 5610–5611
Pattern: 11
Route 01
Pool=8001, PSTN BRI trunks
FRL=5, Data, prepends digits
1410xxx for PRI dial-plan routing
on System E.
Extension Range: 5610–5611
Pattern: 05
Route 01
Pool=6800, tandem PRI trunks
FRL=5, Data
Extension Range: 4530–4599
Pattern: 02
Route 01
Pool=4310, tandem tie trunks
FRL=3, Voice
Extension Range: 5612–5669
Pattern: 01
Route 01
Pool=5260, tandem PRI trunks
FRL=0, Both
Extension Range: 2200–2259
Pattern: 01
Route 01
Pool=8240, tandem tie trunks
FRL=2, Voice
Extension Range: 5612–5669
Pattern: 03
Route 01
Pool=6701, tandem PRI trunks
FRL=0, Both
Continued on next page
