Lucent Technologies MERLIN LEGEND Release 6.1 Network Reference

MERLIN LEGEND Communications System Release 6.1 Network Reference
555-661-150
Issue 1
August 1998
Call-Handling Scenarios
Page 2-84Network Configuration Scenarios
2
Table 2–21. Scenario 4: Facilities Planning, Calls Originating within the Network and Going to the PSTN, Systems F and G
Component System F: Spokane, WA (Area Code: 509) System G: Austin, TX (Area Code: 512)
DS1 Switch Type
MERLIN LEGEND-PBX Not applicable for tandem tie trunks
Switch Identifiers
Programmed on
This System
01 for a system more than 200 miles away (System E) 01 for a system more than 200 miles away (System E)
ARS Routing:
Calls to Local or
Nearby Area
Codes
Digit string: 1509: Area Code Table, Route to pool(s) of
local PSTN facilities, FRL=0, Absorb=4
Digit string: 1512: Area Code Table, Route to pool(s) of
local PSTN facilities, FRL=0, Absorb=4
ARS Routing:
Calls to Area Code
of Non-Local
System or to Area
Codes Near
Non-Local System
(Absorb = 0)
For primary routes serving calls to area codes 410, 703,
and 512, the FRLs are set to low values.
The FRL is higher for primary routes to areas near but not
in the same area code as one of the other private network
systems. For instance, a 703 area code route via a
tandem PRI pool has an FRL of 1.
Secondary routes using the PSTN have FRLs as high
as 6.
For primary routes serving calls to area codes 410, 703,
and 509, the FRLs are set to low values.
The FRL is higher for primary routes to areas near but not
in the same area code as one of the other private network
systems. For instance, a 301 area code (Maryland) route
via the tandem tie pool has an FRL of 2.
Secondary routes using the PSTN have FRLs as high
as 6.
Centralized
VMS/AA
Integrated VMI calling group extension: 7771
VMI conversion number (non-local dial plan member:
6999
UDP routing over route 01, tandem PRI trunks, FRL=0,
voice, all dialed digits are absorbed and the digits 7771
are prepended.
Integrated VMI calling group extension: 7771
VMI conversion number (non-local dial plan member:
6999
UDP routing over route 01, tandem PRI trunks, FRL=0,
voice, all dialed digits are absorbed and the digits 7771
are prepended.
