Call-Handling Scenarios
Page 2-55Network Configuration Scenarios
2
Table 2–12. Intersystem Calling: Scenario 2
Type of Call Caller Caller Dials Recipient Recipient Sees...
Non-local extension System C: Ext. 4638
FRL=6

System D Ext. 7342,
MLX-5D
®
7,(75.
Non-local extension System D, Ext. 7377
FRL=3

System C Ext. 4638,
MLX-20L
7,(75.
Intersystem Remote Access System C, Ext. 4638
FRL=6
 + barrier
code (with FRL
6) +

Routed via UDP Pattern
3, FRL 6, to System D for
remote system
programming
Not Applicable
Transfer of outside call to non-
local extension
Outside to
System C: Ext. 4632
Transfer

System D Ext. 7377,
MLX-10D, has Do Not
Disturb on and no
coverage. Caller hears
busy tone.
Not Applicable
Transfer of outside PRI-ANI call
to non-local extension
Outside to
System C: Ext. 4646,
PassageWay client.
Display pops up
customer information.
Transfer

(Manual
transfer using
telephone)
System D Ext.7358,
MLX-20L
7,(75.
Continued on next page
