Lucent Technologies MERLIN LEGEND Release 6.1 Network Reference

MERLIN LEGEND Communications System Release 6.1
Network Reference 555-661-150
Issue 1
August 1998
Call-Handling Scenarios
Page 2-22Network Configuration Scenarios
2
Table 2–1. UDP Extension Ranges: Scenario 1
System A Local Dial Plan: 3100–3299;
3400–3499
Remote Access Code: 889
Integrated VMI Calling Group for Routing
to Centralized VMS/AA: 771
Trunks: 3801-3880
System B Local Dial Plan: 6700–7199
Remote Access Code: 122
Centralized VMS/AA: 771
Trunks: 8001-8080
Extension Range: 6700–6799, Pattern: 01
Route 01
Pool=3360, tandem PRI trunks
FRL=0, Voice
Route 02
Pool=3365, tandem PRI trunks
FRL=3, Voice
Extension Range: 3100–3199, Pattern: 01
Route 01
Pool=4420, tandem PRI trunks
FRL=0, Voice
Route 02
Pool=4423, tandem PRI trunks
FRL=0, Both
Extension Range: 6800–6999, Pattern: 02
Route 01
Pool=3364, tandem PRI trunks
FRL=0, Both
Route 02, PSTN trunks
Pool=3367, FRL=6, Voice
No dialed digits are deleted and one plus the
area code and exchange are prepended.
Extension Range: 3200–3299, Pattern: 02
Route 01
Pool=4422, tandem PRI trunks
FRL=0, Both
Route 02, PSTN trunks
Pool=4424, FRL=6, Voice
No dialed digits are deleted and one plus the
area code and exchange are prepended.
Extension Range: 7000–7199 (2B data
extensions), Pattern: 03
Route 01
Pool=3366, tandem PRI trunks
FRL=1, Data
Route 02
Pool=3362, tandem PRI trunks
FRL=3, Data
Extension Range: 3400–3499 (2B data
extensions), Pattern: 03
Route 01
Pool=4425, tandem PRI trunks
FRL=1, Data
