MERLIN LEGEND Communications System Release 6.1
Network Reference
555-661-150
Issue 1
August 1998
Call-Handling Scenarios
Page 2-53Network Configuration Scenarios
2
Table 2–11. Outside Calls: Scenario 2, Continued
Originating or
Receiving System Dialed Digits Local Routing Non-Local Routing
System C: Ext. FRL: 1
Route 1: ARS Area Code Table routes to
tandem trunk pool, FRL 3, call prohibited
for this user. Call denied ●
System C: Ext. FRL: 3
Route 1: ARS Area Code Table routes to
tandem trunk pool, FRL 2, prepends 9.
<
Route 2: If all lines in Route 1 are busy,
ARS Area Code Table routes to local
PSTN pool, FRL 4, call prohibited for this
user. Call denied
●
System D: Remote access FRL 3. ARS
absorbs no digits, routes to PSTN pool.
●
System D: Receives
outside dial-plan routed
call to calling group. Too
many callers are waiting
and the call is routed to
centralized VMS/AA.
Call is sent to calling group 7771 with VMI
conversion number (6999)
Route 1: Integrated VMI routes to pool
6130, voice only. UDP route absorbs all
digits and prepends 7771 (extension
number for the centralized VMS/AA at
System C).
<
System C: Call rings into centralized
VMS/AA for calling group 7342 and calling
information indicates an outside call.
When caller leaves message, Message
Waiting light update is sent over the
private network to Message Waiting
receiver for the calling group on System D.
●
< = Call sent over tandem trunks | = Call sent over PSTN ● = Call ends
