MCS640 Thermal Imager Manual Introduction • 11
2.3 Technical Data
Performance
Temperature Ranges:
MCS640/I1 Filter
600 to 1600 °C (MB16) or 800 to 3000°C (MB30) in up
to 4 sub-ranges
MCS640/I5 Filter
600 to 1600 °C (MB16) or 800 to 3000°C (MB30) in
up to 4 sub-ranges
Sub Ranges:
MB16: 600 to 850, 700 to 1000, 850 to 1250, 1100 to 1600
MB30: 800 to 1150,1000 to 1500, 1350 to 2050, 1900 to 3000
Spectral Ranges:
MCS640/I1 Filter
850 nm (I1 filter)
MCS640/I5 Filter
780 to 1080 nm (I5 filter)
Measurement Accuracy:
+/- 0.5% of reading in °K
Repeatability
0.1% of measured value in °K + 1°K
Image Update Rate:
60 Hz (fps; frames per second)
A/D Resolution:
16 bit
Detector:
640 x 480 pixel; Silicon
Emissivity Correction:
10.0 to 100.0% adjustable via interface in steps of 0.1%
(for full camera picture)
Transmittance
10 to 100 % (in application software)
Sensitivity/NETD
MCS640/I1 Filter
1° at 600 °C
MCS640/I5 Filter
1° at 600 °C
Optical Specifications
Field of View:
21° (H) x 16° (V) (standard lens)
Focus Range:
30 cm to infinity
Environmental Specifications
Protection Class:
IP65 (IEC 60529); NEMA 4
Shock Resilience:
30G (IEC60068-2-29/JIS C 0042)
Vibration Resilience:
3G (IEC60068-2-6/JIS C 0040)
Operating Temperature:
0 to 50 °C
Storage Temperature:
-40 to 70 °C
Relative Humidity:
None condensing conditions
Weight:
0.7 kg (1.5 lbs)
Operating Position:
Any orientation
Housing:
Aluminum extrusion
Dimensions:
2.19 in x 2.46 in x 6.5 in (55.6 mm x 62.5 mm x 165.1 mm)
CE-label
According to EU directives about electromagnetic immunity
Interface
Analog:
None
Digital:
Gigabit Ethernet (1000 MBit/s)
Optics:
Manual focus
Connections:
12 pin power connector; RJ45 Ethernet connector
