MCS640 Thermal Imager Manual Introduction • 13
Note: The size of the measured object must be at least 3 x 3 pixels to guarantee precise temperature
determination. This ensures that at least one pixel of the detector is completely covered.
2.6 Camera Interface
The rear panel of the MCS640 supports connectors for the Gigabit Ethernet and DC Power input.
Rear Panel MCS640 Camera
DC Power Entry
Connector
Gigabit Ethernet Connector
