Lumens VC-A61P User Manual

English - 37
3.1
Group Name
The group name can be modified here and set with Access
Manager - Receive in NDI Tool
 If no group is assigned, the machine belongs to Public.
As the default of Access Manager includes Public, Studio
Monitor can discover this machine.
 If a group is assigned, but this group is not added into
Access Manager, Studio Monitor cannot discover this
machine.
 If a group is assigned and this group is added into Access
Manager, Studio Monitor can discover this machine.
The name can contain commas (,) to distinguish different
groups
Example: “default, 123, abc" means this machine
belongs to three groups at the same time (default / 123 /
abc)
Support when
NDI|HX is On
4
Streaming 1/
Streaming 2/
Streaming 3
VC-A61P supports 3 streaming outputs. Please refer to
6.2.5.1 Streaming Parameter Setting for relevant settings
V
Support when
NDI|HX is Off
5
Preview
window
Display the screen currently captured by the camera
V
6
Apply
After the setting has been modified, select this button to
apply the setting
V
V
6.2.5.1 Streaming parameter setting
Function
Streaming 1
Streaming 2
Streaming 3
Encode Format
H.265
H.264
Resolution
4K /1080P / 720P
1080P / 720P / 1080i
640 x 360
Frame Rate
Setting according to the supported resolution
Bit Rate (kbps)
Range
2,000 ~ 20,000
2,000 ~ 20,000
512 ~ 5,000
Factory
Default
7,000
7,000
1,000
Rate Control
CBR/VBR
IP Ratio
Setting according to the supported resolution
