1.Press OK to enter the AUX setting interface.
2.Press OK, the max input current setting item flashes.
3.Press to change the max input current from 10A to 1000A.
4.Press OK. The max input current stops blinking and the max output
voltage flashes.
5.Press to change the max output voltage from 0.1V to 10V.
6.Press MENU to confirm.
7.Press MENU again to exit the current settings.
Aux is defined as current sensor by default. The current of the
external equipment is calculated by setting the parameters of the
current sensor such as the maximum measuring current and the
maximum output voltage. After the correct setting, the external
current will be displayed on the LCD screen of the controller.
1.Press OK to enter the factory reset setting interface and the clear
data is selected.
2.Press OK, the clear log data dialogue appears.
3.Press OK, all log data is deleted and the LCD display "Clear done".
4.Press MENU again to exit the current settings.
5. Repeat steps 3 and 4 for "ReSet BLE password" and "Reset".
Refer to the following figure for the operation steps.
1.6 Set AUX
Clear data
Reset BLE password
Reset
1.7 Factory reset
Clear data
ReSet BLE password
Reset
OK
OK
OK
OK
OK
OK
MENU
MENU
MENU
Clear done
Clear done
Clear done
Reset BLE password
Are you sure?
Menu
OK
Clear log data
Are you sure?
Menu
OK
Reset factory
Are you sure?
Menu
OK
AUX setting
Max in curr. : 1000A
Max out volt. : 10.0V
If "ON" is selected, the automatic maintenance function of the diesel will be
started. If the diesel has not been started within 60 days, the diesel will be
started at night. The working time of the diesel shall not be less than 15 minutes
each time it is started.
"OFF" diesel If is selected, the engine will not start until Utility/Generator relay2
is turned on.
OK
MENU
1.Press OK to enter the diesel setting interface.
2.Press OK, the auto maintain setting item flashes.
3.Press to select the auto maintain item from ON and OFF.
4.Press MENU to confirm.
5.Press MENU again to exit the current settings.
Diesel generator
Auto maint. : ON
1.5 Set diesel
