8. Technical Speci󽘀cations8. Technical Speci󽘀cations
CONNECTIVITY
DMX/RDM 4x RJ45-DMX
Network 2x gigabit RJ45
Contact Closure 1x 2-pin plugable terminal block
Power
1x 3-pin plugable terminal block
PoE-802.3af (Class 0)
DMX FEATURES
Supported protocols
DMX512 (1986 & 1990)
DMX512-A
RDM ANSI E1.20-2010
DMX port direction Input or output (con󽘀gurable)
DMX port isolation Optical and galvanic isolation per port
DMX timing
Framerate: 10-40FPS
Break: 176-352µs
ETHERNET FEATURES
Supported protocols
Art-Net
TM
(1-4)
sACN ANSI E1.31-2018
RTTrPL (BlackTraX)
KiNET v1, v2
Port speed 10/100/1000Mbps
Port sensing
Auto-negotiation
MDI/MDIX
Split management interface Yes
Groups (VLAN) support Yes
ADDITIONAL FEATURES
Process Engine 6
Merging Yes (HTP, LTP, Xfade, Backup, Switch, Custom)
Softpatch Yes
Master/Limit Yes
Trigger system Yes
Reroute function Yes
Pro󽘀le manager Yes
Snapshot Yes
Monitoring Software LumiNet Monitor, Araneo
DMX redundancy Yes
STATUS REPORTING
Display & Jog Yes
Ethernet port connection
Link/activity LED
Group RGB LED
DMX port DMX/RDM RGB LED
POWER/PoE
Power input
12-24VDC
PoE-802.3af (Class 0)
Power consumption Max 10W
Power redundancy Yes
