To quickly assign a universe to a port, scroll to the port number and click the jog wheel.
(A) Port number you are viewing.
(B) Protocol that is congured for this port.
(C) Current universe assigned to this port. Use the jog wheel to change the universe number and press to
conrm. A popup window will appear asking you to conrm the changes.
If a source stream fails on a port the LCD display will show this by changing the Output red.
If the lost stream is recovered the LCD display will show this by changing the Output orange.
This way the user can see the source stream has been lost but has been restored.
24
