Page 4 of 7 11/21/16
Vehicles without tow hooks:
a. Cut out the indented area in both sides of the plastic bumper insert to clear the Brackets as
pictured, (Figures 3 & 4). IMPORTANT: Make several small cuts for best fit. Do not cut through
the top edge of the panel. NOTE: On some later models, the plastic panel is held in place with
several small screws. The screws at the top corners are difficult to impossible to reach and remove
without damaging the cover with the bumper in place. If you prefer to remove the panel to cut out
the openings, it may be necessary or easier to remove the plastic grille then the steel bumper
assembly with the plastic panel attached to access all of the small screws and clips.
b. Reattach the bumper and/or bumper insert, (if removed), and grille once openings have been cut
out and checked for clearance. Tighten all factory bumper hardware at this time.
2. Select the driver side Mounting Bracket. Insert the Bracket through the opening in the bumper, (Figure 5).
Trim the plastic as required to clear the Brackets.
