Lunos Nexxt - Dimensioned Drawings

29
Dimensioned drawings (all dimensions in mm) EN
118 (with reference to blind)
Ne
xx
t—surface mounted
239
118 (with reference to blind)
Ne
xx
t—concealed mounted
Adapter and electrical
flap close-off
Adapter and electrical
flap close-off
510
510
278
510
510
105
66
167 (with refe-
rence to blind)
167 (with refe-
rence to blind)
