Insert the slide-in unit into the wall
installation housing!
Note: The slide-in unit must joint
exactly into the electrical flap
close-off and on the mains
connection circuit board!
With the insertion the electrical
connection of the slide-in unit is
realized!
Place the housing lid onto the wall
installation housing with the slide-
in unit contained in it! Screw the
housing lid onto the wall installa-
tion housing with the enclosed
bolts!
Installation - Finished installation EN
Insert the filters!
Note the correct flow-streaming
direction of the filters, where this
is marked with an arrow!
①
②
Guide the ribbon cable
through the opening in the
housing lid!
